Front Access P3.91 P4.81 Outdoor Led Screen Paper Wall Mounted Aluminum Panel
Specifictions:
1. Front access, slim aluminum cabinet, easy and fast to install and maintenance.
2. 2.8V&3.8V energy saving design, no need air-conditioner, environmental and save cost.
3. Very simple steel structure, wall mounted installation, support seamless splicing at 90 degree corner.
4. Totally warterproof of front and back, certification:CE, FCC, IP65
5. Competitive price, you are welcome to contact us for a free project evaluation.
| Model No. | P10.41 | P7.8 | P6.25 | P5.2 | P4.8 | P3.9 |
| Pixel pitch | 10.4mm | 7.82mm | 6.25mm | 5.2mm | 4.81mm | 3.91mm |
Pixel density
(dots/m2) | 9246 | 16352 | 25600 | 36982 | 43264 | 65536 |
| LED encapsulation | SMD2727 | SMD2727 | SMD2727 | SMD2727 | SMD1921 | SMD1921 |
| Scan rate | 1/2 scan | 1/4 scan | 1/5 scan | 1/6 scan | 1/7 scan | 1/8 scan |
| Module size | 500 x 250 mm |
| Module Resolution | 48 x 24 | 64 x 32 | 80 x 40 | 96 x 48 | 104 x 52 | 128 x 64 |
| Cabinet size | 1000 x 1000 x 73mm (Optional) |
| Cabinet Resolution | 96 x 96 | 128 x 128 | 160 x 160 | 192 x 192 | 208 x 208 | 256 x 256 |
| Weight per Cabinet | 24.5 kg |
| Brightness | ≥6500/
10000nits | ≥6000/
10000nits | ≥6000/
10000nits | ≥5500/ | ≥5000/ | ≥5000/ |
| Max.power consumption | 500W | 500W | 500W | 550W | 800W | 800W |
| Ave.power consumption | 175W | 175W | 175W | 185W | 270W | 270W |
| Energy Saving design | 2.8V & 3.8V Low voltage | 4.6V / 5V voltage |
| Protection Degree | Front IP67/Rear IP65 |
| Service | Front & Rear Dual service |
| Power Supply | AC120 /240V (50Hz) (optional) |
| Refresh Rate | ≥ 1920Hz(3840Hz Optional) |
